| SPECIFICATIONS: | |
|---|---|
| TABLE SIZE | 36" x 14" |
| MAXIMUM TABLE LOAD | 3000 LBS |
| SPINDLE NOSE TO TABLE TOP | 4" - 24" |
| X-AXIS TRAVEL | 30" |
| Y-AXIS TRAVEL | 16" |
| Z-AXIS TRAVEL | 20" |
| RAPID TRAVERSE RATE - ALL AXES | 1000 IPM |
| CUTTING FEED RATE | 0.1-500 IPM |
| SPINDLE SPEEDS | 10,000 |
| SPINDLE TAPER | BT 40 |
| SPINDLE MOTOR (VECTOR DRIVE) | 20 HP AC |
| TOOL CHANGER CAPACITY | 20 |
| MAXIMUM TOOL WEIGHT | 12 LBS |
EQUIPPED WITH:
