| SPECIFICATIONS: | |
|---|---|
| TABLE WORKING SURFACE | 44.4" x 19.76" |
| TABLE LOAD CAPACITY | 1,543 LBS. |
| TRAVELS (X, Y, Z) | 39.4" x 21.6" x 19.7" |
| SPINDLE NOSE TO TABLE | 5.1"-24.8" |
| FEED RATES, ALL AXES | 945 IPM |
| RAPID TRAVERSE RATE, X&Y | 1417 IPM |
| TOOL CHANGER ARM STYLE | 30 |
| SPINDLE HORSE POWER | 25 HP |
| SPINDLE SPEEDS RANGE | 12,000 RPM / Direct Drive |
| SPINDLE TAPER | CAT-40 |
| OVERALL DIMENSIONS | 112" X 95" X 104" |
| APPROXIMATE WEIGHT - NET | 11,100 LBS |
| POWER | 220V / 3 PHASE |
EQUIPPED WITH:
